MSI B560M-A PRO Socket LGA1200/ Intel B560/ DDR4/ SATA3&USB3.2/ M.2/ mATX Motherboard

MSI B560M-A PRO Socket LGA1200/ Intel B560/ DDR4/ SATA3&USB3.2/ M.2/ mATX Motherboard

MSI

Processor:

  • Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors , Pentium Gold and Celeron Processors
  • Processor socket LGA1200

Chipset: Intel B560 Chipset

Memory:

  • 2x DDR4 memory slots, support up to 64GB
  • Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR)
  • Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR)
  • Max overclocking frequency:
    • - 1DPC 1R Max speed up to 5200 MHz
    • - 1DPC 2R Max speed up to 4700+ MHz
  • Supports Dual-Channel mode
  • Supports non-ECC, un-buffered memory
  • Supports Intel Extreme Memory Profile (XMP)

Expansion Slots:

  • 1x PCIe x16 slot (From CPU)
    • - Support up to PCIe 4.0 for 11th Gen Intel CPU
    • - Support up to PCIe 3.0 for 10th Gen Intel CPU
  • 2x PCIe 3.0 x1 slots (From B560 chpiset)

Onboard Graphics:

  • 1x VGA port, supports a maximum resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz
  • 1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz

Audio:

  • Realtek ALC897 Codec: 7.1-Channel High Definition Audio

Lan: 1x Realtek 8125B 2.5Gbps LAN controller

Storage:

  • 6x SATA 6Gb/s ports (From B560 chipset)
  • 1x M.2 slot (Key M)
    • - Supports up to PCIe 4.0 x4 for 11th Gen Intel CPU (From CPU)
    • - Supports up to PCIe 3.0 x4 & SATA 6Gb/s for 10th Gen Intel CPU (From B560 chipset)
    • - Supports 2242/ 2260/ 2280 storage devices
  • Supports Intel Smart Response Technology for Intel Core processors

USB:

  • Intel B560 Chipset
    • - 6x USB 2.0 ports (2 Type-A port on the back panel, 4 ports available through internal USB 2.0 connectors)
    • - 6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports available through internal USB 3.2 Gen1 connector)

BIOS Features:

  • 1x 256 Mb flash
  • UEFI AMI BIOS
  • ACPI 6.2, SMBIOS 3.0
  • Multi-language

Internal Connectors:

  • 1x 24-pin ATX main power connector
  • 1x 8-pin ATX 12V power connector
  • 6x SATA 6Gb/s connectors
  • 1x M.2 slot (M-Key)
  • 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
  • 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
  • 1x 4-pin CPU fan connector
  • 1x 4-pin system fan connector
  • 1x Front panel audio connector
  • 2x System panel connectors
  • 1x Chassis Intrusion connector
  • 1x Clear CMOS jumper
  • 1x TPM module connector
  • 1x Serial port connector
  • 1x Tuning Controller Connector

Back Panel Ports:

  • HDMI
  • VGA
  • Mouse / Keyboard
  • LAN port
  • Audio connector
  • USB 2.0
  • USB 3.2 Gen 1 5Gbps Type-A
  • USB 3.2 Gen 1 5Gbps Type-A

Dimensions:

  • mATX Form Factor
  • 9.3 in. x 8 in. (23.6 cm x 20.2 cm)

Operating System: Support for Windows 10 64-bit
